Open Well Submersible 3hp 65x65mm C.I. Body (aluminium Rotor) V-7 YM-323

Open Well Submersible 3hp 65x65mm C.I. Body (aluminium Rotor) V-7 YM-323

Brand: Yash Pumps

Categories: Single Phase Water Pumps, Open Well Submersible Pumps, 3.00 HP,

Availability: In Stock

Cash on delivery Availability: NO

Price: Rs 18,062.00 Rs 16,499.00
Qty:

V-7 C.I. BODY OPENWELL SUBMERSIBLE PUMP SET 3.00 H.P. (65X65) SINGLE PHASE (Aluminium Rotor)


YM-323

Approved by ISI


46 BEE( BUREAU OF ENERGY EFFICIENCY) 5 Star Model

Description:
SALIENT FEATURES
→  Specially designed to start in low voltage and sustain in high voltage fluctuations.
→  High electrical and mechanical efficiency.
→  Higher heat dissipation.
→  Dynamically balanced rotor and other rotating parts for uniform clearance.
→  Specially designed bearing to withstand axial thrust loads.
→  Designed for high voltage fluctuations.
→  Noise free operation.
→  Modular design and all parts are easily interchangeable.
→  Energy Efficient Models.
→  Higher efficiency resulting in lower operating cost.

APPLICATION
→  Agriculture Farm
→  Industries Water Supply
→  Sprinkler & Drip Irrigation
→  Gardens
→  Residential Complex
→  Hospitals
→  Water Treatment Plant

TECHNICAL DATA
MODEL →  YM-323
POWER →  2.20 Kw
H.P. →  3.00
STAGE →  01
CURRENT IN AMPS →  16.00
VERSION →  SINGLE PHASE  140 TO 240 VOLT
RATED SPEED IN RPM →  2880
FREQUENCY →  50 Hz
CATEGORY →  B
DUTY TYPE →  S1 (CONTINUOUS)
TYPE →  WET TYPE
CONNECTION →  PARALLEL  (CSCR)

OPERATING DATA
DUTY POINT HEAD →  18 METERS
DUTY POINT DISCHARGE →  575 LPM  34.50 m³/hr
OPERATING HEAD RANGE →  14 TO 22 METERS
OPERATING DISCHARGE RANGE →  664 TO 387 LPM
SUCTION
DELIVERY		 →  65 MM  (2.5")
→  65 MM  (2.5")
CORRECT SPEED IN RPM →  2840
MAXIMUM FLOW RATE →  838 LPM  50.28 m³/hr
TOTAL HEAD
MAXIMUM OPERATING PRESSURE		 →  24 METERS
→  2.40 Bar
MAXIMUM LIQUID TEMPERATURE →  35º

PARTICULARS MATERIALS OF CONSTRUCTION
MOTOR BODY →  CI - FG -200
BEARING BUSH →  LTB - 4 BRONZE
MOTOR SHAFT →  S.S.410
THRUST BEARING →  S.S. 420 RING & FIBER PLATE
HOUSING / BACK COVER →  CI - FG -200
STAMPING →  CRNO - M45
SCREWS / STUDS / OTHER PARTS →  S.S. 410 & S.S. 202
IMPELLER
CASING		 →  CI - FG - 200
→  CI - FG - 200
WINDING WIRE →  E.C. GRADE COPPER / HIGH INSULATION
ROTOR  →  ALUMINUM DRY CAST & CRNO - M45

​Manufactured, Marketed, and Dispatched by: Yash Manufacturers

Guarantee:
One year Guarantee on manufacturing defects (excluding winding).
Winding is not at all covered in guarantee/warranty clause.
Manufacturer is committed for best after sales services.
For warranty related issue, send email to: [email protected]  & cc to: [email protected]
